MIL-PRF-53012 Suspension Kit, Collapsible HoselineThis specification covers kits containing items necessary to suspend a 6- or 4-inch collapsible hoseline at road crossings, small streams, and areas where nestable culverts or road guards may not be used.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12


MIL -PRF-53012A
TRIPOD TOWER
(NOT SUPPLIED WITH KIT)
BLOCK
SHACKLE
HOSE
SADDLE
WIRE ROPE
WIRE ROPE CLIP
WIRE ROPE THIMBLE
5 FOOT
INTERVALS
TURNBUCKLE
FIBER ROPE
ANCHOR
(GROUND)
HOIST
(USED FOR TEMPORARY
TENSIONING OF WIRE ROPE)
(USED ONLY IN TYPE I KIT)
FIGURE 1. Kit components installation (typical).
