MIL-PRF-53013 Repair Kit, 6-Inch HoselineThis specification covers a repair kit consisting of tools and materials necessary for permanent repair to the Inland Petroleum Distribution System \(IPDS\) 6-inch, lightweight, collapsible hose-line. The components are contained in a fitted storage chest.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12


MIL-PRF-53013B
(C Nom.)
(D Nom.)
(B)
(A)
(B)
Nom.
Nom.
Nom.
I.D.
(E Nom.)
Nom.
Approx
Hose Wall
Hose
Size
Dimensions
Wgt
Thickness
I.D.
A
B
I.D.
O.D.
E
D
C
Lb*
Min
Max
6.00
1.40
2.70
5.40
N/A
4.90
9.80
6.80
7.50
0.09  0.21
6.00
* Nipple and clamp assembly complete.
NOTES:
1. Dimensions are in inches.
2. Tolerances .XX ± .06.
FIGURE 3. Hose Repair Assembly, Grooved End - Example.
9
