MIL-PRF-53013B
3.2.1 Identification of materials and finishes. The contractor shall identify and document the
specific materials, material finish, or treatment for use with components and sub-components.
3.2.2 Recovered material. The offerer/contractor is encouraged to use recovered materials
(see 6.6.2) to the maximum extent practicable, in accordance with paragraph 23.403 of the
Federal Acquisition Regulation (FAR).
3.2.3 Deterioration prevention and control. The equipment shall be fabricated from
compatible materials, inherently corrosion resistant or treated to provide protection against the
various forms of corrosion and deterioration to which the materials are susceptible.
3.2.3.1 Dissimilar metals. Dissimilar metals shall not be used in intimate contact with each
other unless protected against galvanic corrosion.
3.3 Repair kit parts list. The components comprising the repair kit and their required
quantities are listed in table I.
TABLE I. 6-Inch Hose-Line Repair Kit Parts.
Qty.
Description
Ref No.
3
Coupling, clamp, 6 inch nom. size
A-A-52598
6
Gasket, coupling, 6 inch nom. size
A-A-52598
2
Clamp, hose, 6 inch
(figure 1)
18
Hose nipple assembly, grooved end, three-segment, 6 inch
(figure 2)
6
Hose repair assembly, grooved end, three-segment, 6 inch
(figure 3)
6
Adapter assembly, hose, double grooved end, three-segment, 6 inch
(figure 4)
1
Set, wrench, socket, 12 point, 1/2 drive
(3.6.1)
1
Shears, 8 inch nom. size.
( 3.6.2)
Knife, rubber cutting, non- conductive handle, 8.00 in. × 1.00 in.
1
(3.6.3)
3.4 First article. Unless otherwise specified (see 6.2), a sample shall be subjected to first
article inspection in accordance with 4.2.
3.5 Hose clamp. The hose clamp shall consist of a base, fastener, frame, crosshead, and a
screw and screw handle (pictured) or other means for lowering the crosshead and compressing
the hose (see figure 1).
3.5.1 Base. Means shall be provided for latching and pivoting the vertical frame.
3.5.2 Fastener. The fastener shall be self-actuating and affixed to the base in such a manner
that it may move freely. Means shall be provided for quickly engaging and locking the movable
side of the frame.
3
